Modern Android apps quickly become complex. Without a proper structure, Activities and ViewModels turn into massive, unmaintainable classes.

This is where Clean Architecture becomes a game changer.

In this guide, you’ll learn:

✔ What Clean Architecture is
✔ Why it matters in Android development
✔ Layered structure explained
✔ Dependency rules
✔ Practical Kotlin examples
✔ Common mistakes to avoid

---

✅ What is Clean Architecture?

Clean Architecture is a software design pattern that separates an application into distinct layers, ensuring:

• Clear separation of concerns
• Framework independence
• High testability
• Scalability & maintainability

Core philosophy:

Business logic should not depend on UI, databases, or frameworks.

---

✅ Why Clean Architecture is Important in Android

Without architecture:

❌ UI & logic tightly coupled
❌ Hard to test
❌ Difficult to scale
❌ Fragile codebase

With Clean Architecture:

✅ Testable business rules
✅ Flexible technology choices
✅ Clean & modular code
✅ Easier debugging

---

✅ The Three Core Layers

Android Clean Architecture typically consists of:

1. Presentation Layer
2. Domain Layer
3. Data Layer

Each layer has a distinct responsibility.

---

---

🟢 1. Presentation Layer (UI & State Management)

Responsible for:

✔ Displaying UI
✔ Handling user actions
✔ Managing UI state

Contains:

• Activities / Fragments / Composables
• ViewModels
• UI State classes

Example structure:

presentation/
    ├── ui/
    ├── viewmodel/
    └── state/

---

✅ Example ViewModel

class UserViewModel(
    private val getUserProfileUseCase: GetUserProfileUseCase
) : ViewModel() {    private val _state = MutableStateFlow<UserState>(UserState.Loading)
    val state: StateFlow<UserState> = _state    fun loadUser(userId: String) {
        viewModelScope.launch {
            try {
                val user = getUserProfileUseCase(userId)
                _state.value = UserState.Success(user)
            } catch (e: Exception) {
                _state.value = UserState.Error(e.message ?: "Unknown error")
            }
        }
    }
}

---

✅ UI State Representation

sealed class UserState {
    object Loading : UserState()
    data class Success(val user: User) : UserState()
    data class Error(val message: String) : UserState()
}

👉 Notice: No API / DB logic here.

---

---

🟡 2. Domain Layer (Core Business Logic)

The most important layer.

Responsible for:

✔ Business rules
✔ Use cases
✔ Core models
✔ Framework independence

Contains:

• UseCases
• Domain Models
• Repository Interfaces

Example structure:

domain/
    ├── model/
    ├── repository/
    └── usecase/

---

✅ Domain Model Example

data class User(
    val id: String,
    val name: String,
    val email: String
)

Pure Kotlin → No Retrofit / Room / Android.

---

✅ Use Case Example

class GetUserProfileUseCase(
    private val repository: UserRepository
) {
    suspend operator fun invoke(userId: String): User {
        return repository.getUser(userId)
    }
}

UseCases encapsulate single business actions.

---

✅ Repository Interface

interface UserRepository {
    suspend fun getUser(userId: String): User
}

👉 Domain defines contract, not implementation.

---

---

🔵 3. Data Layer (Implementation Details)

Responsible for:

✔ API calls
✔ Database operations
✔ Mapping models
✔ Repository implementations

Example structure:

data/
    ├── remote/
    ├── local/
    ├── mapper/
    └── repository/

---

✅ API DTO Example

data class UserDto(
    val id: String,
    val full_name: String,
    val email_address: String
)

---

✅ Mapper Example

fun UserDto.toDomain(): User {
    return User(
        id = id,
        name = full_name,
        email = email_address
    )
}

DTO → Domain Model conversion is critical.

---

✅ Repository Implementation

class UserRepositoryImpl(
    private val api: UserApi
) : UserRepository {    override suspend fun getUser(userId: String): User {
        return api.getUser(userId).toDomain()
    }
}

---

✅ Dependency Flow (Very Important)

Data flow:

UI → ViewModel → UseCase → Repository → Data Sources

Dependency rule:

Presentation → Domain → Data

Never:

Domain → Android ❌
Domain → Retrofit ❌

---

✅ Key Benefits of Clean Architecture

---

✅ 1. High Testability

Domain layer = Pure Kotlin → Easy unit tests.

---

✅ 2. Scalability

Project grows → Layers remain manageable.

---

✅ 3. Replaceable Technologies

Swap:

✔ Retrofit → Ktor
✔ Room → SQLDelight
✔ XML → Compose

Without rewriting business logic.

---

✅ 4. Cleaner Codebase

Responsibilities are predictable & isolated.

---

✅ Common Mistakes Developers Make

Avoid these:

❌ Business logic inside ViewModel
❌ API models used as domain models
❌ Skipping UseCases in complex apps
❌ Domain layer depending on frameworks

---

✅ When Should You Use Clean Architecture?

Best for:

✅ Medium & Large apps
✅ Long-term projects
✅ Team-based development
✅ Complex business logic

Overkill for:

✔ Tiny apps
✔ Prototypes / POCs

---

✅ Mental Model to Remember

Think of layers like:

🏛 Presentation = UI layer
🧠 Domain = Brain / logic
🔌 Data = External systems
